Product Features

Adopts advanced ergonomic design

Comfortable grip, sturdy and long service life

Dustproof and waterproof construction

Multiple button combinations, toggle switches can be additionally installed

Application Range

Industrial control handles

Electronic control armrest boxes

Control panels

Electro-hydraulic control systems

Technical Specifications

Mechanical Parameters

1 to 6 buttons can be mounted on the panel, with optional additional toggle switches

Button operating force: approx. 5 N

Button type: momentary self-reset or latching

Mechanical service life of buttons: over 1,000,000 cycles

Electrical Parameters

Electrical service life of buttons: more than 1,000,000 cycles

Rated button current: 50 mA

Button insulation resistance: >1000 MΩ

Environmental Parameters

Operating temperature: -30°C ~ +80°C

Storage temperature: -40°C ~ +85°C
